Inconel 718 Round Bar
Buy Large Or Small Quantity From Inconel 718 Rod Suppliers, Nickel 718 Square Bar And Alloy 718 Flat Bar, ASTM B637 UNS N07718 Bar Stockist In Mumbai At Discounted Prices
Rythme Alloys is a manufacturer, exporter, and supplier of Inconel 718 Round Bar and uses premium quality raw materials and available materials to enhance the product’s ability to provide the best products. We also offer a wide range of custom-made products on customer’s prerequisites.
Inconel 718 Round Bar is a precipitation-hardened nickel chromium based super alloy. The ASTM B637 UNS N07718 Bright Bar contains also significant amounts of elements like iron, niobium, and molybdenum along with trace amounts of metals like aluminium and titanium. Aluminium and titanium make the Inconel 718 hardenable.
AMS 5662 Inconel 718 Black Bar is well suited for applications which require high tensile strength in temperature ranges from cryogenic up to an elevated temperature of about 1400°F. Besides having excellent tensile, the ASTM B637 Bar exhibits good impact strength.
The AMS 5663 Bar has a combination of good mechanical & physical properties such as corrosion resistance and high strength with outstanding weld ability. The Alloy 718 Round Bar has good weld able properties includes the alloys resistance to post weld cracking.
We Have A Huge Selection Of Inconel 718 Hex Bar, 2.4668 Inconel 718 Bar, ASTM B637 UNS N07718 Material, AMS 5663 Bar At Low Prices In Mumbai, India
Inconel 718 Round Bar Specification
| Specification | ASTM B637 UNS N07718, ASTM B 637 / ASME SB 637, Inconel Alloy 718 AMS 5662, AMS 5663, AMS 5664, PWA 1009 PWA 1010 GE B50TF15 |
|---|---|
| Grade | Inconel 718 – UNS N07718 |
| UNS N07718 Hex Bar size | 2-100mm A/F |
| ASTM B637 Alloy 718 Round bar size | Diameter: 3-~800mm |
| ASTM B637 Alloy 718 Square bar size | 4 to 100mm |
| N07718 Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Alloy 718 Rectangles Size | 33 x 30mm to 295 x 1066mm |
| ASTM B637 N07718 Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| UNS N07718 Section | 3.0 to 12.0mm thickness |
| Inconel 718 AMS 5666 Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| N07718 Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| ASTM B637 N07718 Billet Size | 1/2″ to 495mm Diameter |
| Round Bar Standard Dimensions | Diameter / Height: |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Hot Rolled Pickled, Bright, Sand Blasting Finished, Cold Drawn, Hairline, Polished |
| Condition | Hardened & tempered, annealed |
| Technique | Inconel 718 Cold Drawn, Hot Rolled, Forged Round Bar,Cold Rolled, Rod |
| Processing | Bar cutting to 650mm |
Alloy 718 Round Bar Condition
H&T | Hardened and tempered. |
ANN | Annealed |
PH | Precipitation hardened. |
AMS 5663 Bar Surface finish
CD | Cold drawn | P | Polished |
BD | Bright drawn | SRE | Slit rolled edge |
CG | Centreless ground | HF | Hot finished |
CF | Cold finished | HRAP | Hot rolled annealed and pickled |
P&T | Peeled and turned | RT | Rough turned/peeled |
ST | Smooth turned | PR | Peeled and reeled |
ASTM B637 UNS N07718 Round Bar Sizes
Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
Cold Drawn and Polish | 3.00 – 75.00 | 1/8 – 3.00 | h8-h9-h10-h11 |
Cold Drawn and Ground | 10.00 – 75.00 | 5/6 – 2.50 | h8-h9-h10-h11 |
Peeled and Polished | 40.00 – 150.00 | 1.50 – 6.00 | h11, h11-DIN 1013 |
Peeled and Ground | 20.00 – 50.00 | 3/4 – 2.00 | h9-h10-h11 |
2.4668 Inconel 718 Bar Mechanical Properties
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.2 g/cm3 | 1350 °C (2460 °F) | Psi – 135,000 , MPa – 930 | Psi – 70,000 , MPa – 482 | 45 % |
Inconel 718 Round Bar Chemical Composition
| Grade | Ni | Cr | Cu | C | Mn | S | Mo | Si | Co |
|---|---|---|---|---|---|---|---|---|---|
| Inconel 718 | 50 – 55 | 17 – 21 | 0.3 max | 0.08 max | 0.35 max | 0.015 max | 2.8 – 3.3 | 0.35 max | 1.0 max |
Inconel 718 Bar Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS |
|---|---|---|
| Inconel 718 | 2.4668 | N07718 |
