Inconel 600, 601, 625 Sheets, Plates and Coils
Inconel 600/601/625 Sheets Plates and Coil, Inconel 601 Cold Rolled Coils, Inconel Alloy N06601 Coils, ASTM B168 Inconel HR Sheets and Plate Manufacturer, NCF 600 Sheets, UNS N06600 Plate, Inconel Industrial Sheets, Plates and Coils Supplier in Mumbai India.
Inconel 600, 601, 625 Sheets, Plates and Coils are used in the industrial applications which are working in the high temperature. However, the sheets and plates are good at working in the pressure applications which are having good strength and high toughness. In addition to this, the sheets and plates are available in many types so that they are used in the applications. The sheets and plates are selected and used according to the applications available in the industries.
These Inconel alloys are widely recognized for their resistance from corrosion in high temperature and aqueous or low temperature. Each alloy has its distinct advantages, and each is used in multiple industries. For a case, Inconel 601 and 600 have both efficient roles in the chemical and food processing industries. Whereas Inconel 625 differs from other alloys as it consists of sufficient nickel, molybdenum, and chromium, as they are effective in splitting corrosion, they have been chosen for making materials in aerospace and marine engineering industries.
Inconel Alloy 2.4856 Slit Coils, Inconel Alloy N06625 Perforated Sheets, Inconel 2.4668 Shim Sheets, Incoloy 600/601/625 Strips Plates and Coil, ASME SB168 Alloy 601 Sheets Stockist, Alloy 600, 601, 625 Sheets, Plates, Coils Exporter in India.
Specification of Inconel 600/601/625/Sheets and Plates
| Specification | EN, DIN, JIS, ASTM, BS, ASME, AISI, IS |
| Size Range | 1 MM To 200 MM Thk In 1000 MM To 3000 MM Width x 2500 MM/ 5000 MM / 10000 MM Length & In Coil Form above as per the customer requirement. |
| Type | 2B, CR, MAT, MAT PVC, BA, MIRROR FINISH |
| Form | Sheet , Plate , Coils, Farma & Different Shape as per drawing |
| TEST CERTIFICATES | MTC, IBR & Third Party Inspection. |
|---|
Mechanical Properties Of Inconel 600/601/625 Sheets and Plates
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
Chemical Composition of Inconel 600, 601, 625 Sheets and Plates, Coils
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Inconel 601 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
Equivalent Grades of Inconel 600 / 601 / 625 Sheets, Plates and Coils
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 600 | 2.4816 | N06600 | NCF 600 | NA 13 | МНЖМц 28-2,5-1,5 | NC15FE11M | NiCr15Fe |
| Inconel 601 | 2.4851 | N06601 | NCF 601 | NA 49 | XH60BT | NC23FeA | NiCr23Fe |
| Inconel 625 | 2.4856 | N06625 | NCF 625 | NA 21 | ХН75МБТЮ | NC22DNB4M | NiCr22Mo9Nb |
