Incoloy 800,800H,800HT Sheets, Plates and Coils
Incoloy 800,800H,800HT Sheets, Incoloy 800HT Cold Rolled Coils, Incoloy Alloy N08810 Coils, ASTM B409 Incoloy 800,800H,800HT HR Sheets and Plate Manufacturer, Incoloy 800,800H,800HT Industrial Sheets, Plates and Coils Supplier in Mumbai India.
Incoloy 800,800H,800HT Sheets, Plates and Coils are available with different specifications, standards, dimensions, shapes, and others. This is the way that the sheets and plates are used in the industries with the applications for working smoothly. Some of the industries which are using the types of sheets and plates are rail fabrication, chemical processing, shipbuilding, carpentries, automotive, boilers, general fabrication, and beverage applications. It is the reason that the industries are having the proper working with the applications.
Both 800H and 800HT are typically considered as premium alloys to the Inconel 800.Inconel 800 alloy is one of the first alloys, and it is little modified into 800H. This modification is basically for controlling carbon from 0.05-0.10% and optimizing stress rupture properties. Inconel 800HT also forward has improvements combined with titanium and aluminum levels of 1% to ensure access to high temperatures. In addition, both alloys obtain elevated temperatures to produce about a usual grain size of coarser. The nickel alloy combines with both 800H and 800HT. Therefore, it is dual certified.
Incoloy Alloy 1.4859 Slit Coils, Alloy N08811 Perforated Sheets, Incoloy 2.4858 Shim Sheets, Incoloy 800/800H/800HT/ Strips, Inconel Alloy 800, 800H, 800HT Sheets, Plates, Coils Exporter in India.
Specification of Incoloy 800,800H,800HT Sheets, Plates and Coils
| Specification | EN, DIN, JIS, ASTM, BS, ASME, AISI, IS |
| Size Range | 1 MM To 200 MM Thk In 1000 MM To 3000 MM Width x 2500 MM/ 5000 MM / 10000 MM Length & In Coil Form above as per the customer requirement. |
| Type | 2B, CR, MAT, MAT PVC, BA, MIRROR FINISH |
| Form | Sheet , Plate , Coils, Farma & Different Shape as per drawing |
| TEST CERTIFICATES | MTC, IBR & Third Party Inspection. |
|---|
Alloy 800 / 800H/800HT Sheets, Plates and Coils Mechanical Properties
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 800 / 800HT / 800HT | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
Chemical Composition of Incoloy 800/800H/800HT Sheets, Plates and Coils
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| 800 | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| 800HT | 0.05 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| 800HT | 0.06 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60ᴬ | 0.15 – 0.60ᴬ |
Equivalent Grades of Incoloy 800/800H/800HT Sheets, Plates and Coils
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN | OR |
| Incoloy 800 | 1.4876 | N08800 | NCF 800 | NA 15 | ЭИ670 | Z8NC32-21 | X10NiCrAlTi32-20 | XH32T |
| Incoloy 800HT | 1.4958 / 1.4876 | N08810 | NCF 800HT | NA 15(H) | ЭИ670 | Z8NC33-21 | X5NiCrAlTi31-20 | XH32T |
| Incoloy 800HT | 1.4859 / 1.4876 | N08811 | NCF 800HT | NA 15(HT) | ЭИ670 | – | X8NiCrAlTi32-21 | XH32T |
