Inconel 600/601/625/718 Buttweld Pipe Fittings
Inconel 600 Pipe Fittings, ASTM B366 Inconel Alloy 601 Buttweld Fittings, UNS N06600 Pipe Elbow, ASME SB366 Inconel Alloy 625 Pipe Bend Exporter, DIN 2.4816 Stub End, UNS N06601 Seamless Fittings, ANSI B16.9 Alloy 600 Pipe Cap, Inconel 718 Butt weld Pipe Fittings Manufacturer in India.
Rythme Alloys is a Leading exporter and manufacturer of Inconel 600/601/625/718 Buttweld Pipe Fittings. The style of the management is the key to the company due to which Inconel Buttweld Fittings is supplied to the customer.
The Inconel 600/601/625/718 Buttweld Fittings is a product that offers many reliable features that are protected against cracks and rust. If the product is crack free then the life span of the product automatically increases. And it also has protection from several other properties like pitting/oxidation, crevice resistance. Even the product is also providing you with greater tensile strength than any other product. With properties like flexibility, rugged construction, high durability, ability to face heavy temperatures are the key features of the product. The buttweld fitting is capable of handling temperature and atmospheric pressure. All this is capable due to the quality of the alloy.
Inconel 600 Piggable Bend Stockist, MSS SP-43 or MSS SP-79 Inconel 601 Welded Pipe Fittings, UNS N06625 LR Elbow, DIN 2.4851 SR Elbow Trader, Inconel® Alloy 625 Reducer Dealer, Alloy 718 Buttweld Elbow, UNS N07718 Reducing Cross, ANSI B16.28 Inconel 600/601 Equal Tee, Inconel ASTM B366 Fitting Supplier in India.
Specification of Inconel 600/601/625/718 Buttweld Pipe Fittings
| Specifications | ASTM B366 / ASME SB366 |
| Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Size | Seamless Butt Weld Fittings : 1/2″ – 10″ | Welded Butt Weld Fittings : 1/2″ – 48″ |
| Schedule | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom |
| Type | Seamless / ERW / Welded / Fabricated |
| Thickness | 20 Swg., 18 Swg., 16 Swg., 14 Swg., 12 Swg., 10 Swg., & Sch. 10, Sch. 40, Sch. 80 etc. |
Mechanical properties of Inconel 600/601/625/718 Buttweld Pipe Fittings
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
| Inconel 718 | 8.2 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 482 | 45 % |
Chemical Composition of Inconel 600/601/625/718 Buttweld Pipe Fittings
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
|---|---|---|---|---|---|---|---|---|
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Inconel 601 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Inconel 718 | 0.08 max | 0.35 max | 0.35 max | 0.015 max | 0.30 max | – | 50.00 – 55.00 | 17.00 – 21.00 |
Equivalent Grades of Inconel 600/601/625/718 Buttweld Pipe Fittings
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| Inconel 600 | 2.4816 | N06600 | NCF 600 | NA 13 | МНЖМц 28-2,5-1,5 | NC15FE11M | NiCr15Fe |
| Inconel 601 | 2.4851 | N06601 | NCF 601 | NA 49 | XH60BT | NC23FeA | NiCr23Fe |
| Inconel 625 | 2.4856 | N06625 | NCF 625 | NA 21 | ХН75МБТЮ | NC22DNB4M | NiCr22Mo9Nb |
| Inconel 718 | 2.4668 | N07718 | – | – | – | – | – |
