Stainless Steel 904L Flanges
SS 904L Ring Type Joint – RTJ Flanges, Stainless Steel 904L Flanges, ASTM A182 Stainless Steel 904L Flanges Supplier, ASTM A182 Stainless Steel 904L Blind Flanges Exporter, Stainless Steel 904L Weld Neck Flanges, SS ASTM A182 F904L Long Weld Neck Flanges, SS 904L Slip on Flanges, SS 904L Flanges Manufacturer in India.
Rythme Alloys is the main producer of the Stainless Steel 904L Flanges. Apart from locals we are providing and trading the Flanges to customers accessible around the world. We are likewise considered among the notable bulk suppliers and shippers.
The quality of the steel which is used to manufacture can helps it to bear very high temperatures. One of the best aspects of it is that it is having very good corrosion resistance ability. More general attributes like anti-corrosive body, rugged construction, toughness, SCC/pitting resistance is making is making it good to use product in typical applications.
In SS 904L Flanges other factors like measurements, shapes, sizes, length, and durability are also considered. There are also flanges in Aluminium, Copper, and Polypropylene etc. It gives protection from oxidation too. These metals give it a shiny surface with high efficiency. Stainless steel is used to make flanges to protect them from different environmental conditions. It can also prevent flanges from rust. Regular cleaning and modification can easily be done. Furthermore, flanges can be categorized in different grades stainless steel grades, copper grades, duplex grade, nickel alloy grade etc.
SS DIN 1.4539 Spectacle Blind Flanges Dealer, DIN 1.4539 Pipe Flanges, Stainless Steel UNS N08904 Plate Flanges, 904L Stainless Steel Threaded Flanges Stockists, ASTM A182 SS F904L SORF Flanges, UNS N08904 Socket Weld Trader, ASME SA182 SS 904L Flanges Supplier in India.
Specification of Stainless Steel 904L Flanges
Stainless Steel Flanges Specification | ASTM A182 / ASME SA182 |
Dimension Standard | ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc. |
Size | 1/2″ (15 NB) to 48″ (1200NB) |
Class / Pressure | 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc. |
Flange Face Type | Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ) |
DIN Flanges | DIN 2527, 2566, 2573, 2576, 2641,2642, 2655, 2656, 2627, 2628, 2629, 2631, 2632, 2633, 2634, 2635, 2636, 2637,2638, 2673. |
JIS Flanges | JIS B2220 5K, JIS B2220 10K, JIS B2220 16K, JIS B2220 20K |
Mechanical Properties Of Stainless Steel 904L Flanges
Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
---|---|---|---|---|---|
Rockwell B (HR B) | Brinell (HB) | ||||
904L | 490 | 220 | 36 | 70-90 typical | 150 |
Chemical Composition of Stainless Steel 904L Flanges
C | Cr | Cu | Mn | Mo | Ni | P | S |
---|---|---|---|---|---|---|---|
Max | Max | Max | Max | ||||
0.02 | 19.0-23.0 | 2.0 | 4.0-5.0 | 23.0-28.0 | 0.045 | 0.035 | 1.0 |
904L Stainless Steel Flanges Equivalent Grades
STANDARD | UNS | WNR. | JIS | BS | KS | AFNOR | EN |
---|---|---|---|---|---|---|---|
SS 904L | N08904 | 1.4539 | SUS 904L | 904S13 | STS 317J5L | Z2 NCDU 25-20 | X1NiCrMoCu25-20-5 |
