Stainless Steel 347/347H Sheets, Plates and Coils
SS 347/347H Perforated Sheets, SS ASTM A240 347 Plates, ASTM A240 Stainless Steel 347 Sheets Exporter, SS 347H CR Sheets, Stainless Steel #4 Finish Plates, Stainless Steel 347H Shim Sheets, ASTM A240 Stainless Steel 347/347H Coils Supplier, 347H Stainless Steel Chequered Plates Stockists, Stainless Steel 347 Hot Rolled Plates, SS 347/347H Sheets and Plates Manufacturer in India.
Rythme alloys are the manufacturers and suppliers of Stainless Steel 347/347H Sheets, Plates and Coils. Alloy 347 Sheets and Plates are the austenitic stainless steels. Three hundred forty-seven have very good mechanical properties, which also results in being useful in high-temperature environments.
Alloy 347 Sheet Plate and Coil maintains stainless steel and plates and provides many benefits such as outstanding resistance to intergranular corrosion by temperature exposure in chromium carbide rapidity ranges up to 816℃. Alloys 347 Sheets are composed of Chromium, Nickel, Carbon, Manganese, Phosphorus, Sulfur, Silicon and Iron. Three hundred forty-seven sheets of steel also have the addition of columbium and tantalum. Hence, 347 is also referred to as Columbium Steel.
SS 347 Sheets cannot be durable by the heat treating method. They can only get hard from cold working conditions. However, the standard manufacturing processes easily machine these 347 Plates. They have received shapes and sizes depending upon national as well as international standards of raw materials. These 347 plates of steel are also popularly called UNS S34700. Alloy 347 also offers higher stress and creep-rupture properties than alloy 304 and especially Alloy 304L.
We assure high quality with top grade and lustrous products to pass from very strict tests for the better products to our respective clients.
UNS S34709 Strips, Jindal Steel Stainless Steel 347 Hot Rolled Plates, Stainless Steel UNS S34700 Shim Sheets, DIN 1.4550 Plates, Stainless Steel 347 #8 Mirror Finish Plates, ASTM A240 SUS 347 Cold Rolled Sheets, SS DIN 1.4961 Sheets Dealer, SS 347H 2B Finish Plates, 347/347H Stainless Steel Chequered Plates Stockists, ASME SA240 SS 347H Sheets and Plates Supplier in India.
Specification of Stainless Steel 347/347H Sheets, Plates, Coils
Specification | EN, DIN, JIS, ASTM, BS, ASME, AISI, IS |
Size Range | 1 MM To 200 MM Thk In 1000 MM To 3000 MM Width x 2500 MM/ 5000 MM / 10000 MM Length & In Coil Form above as per the customer requirement. |
Type | 2B, CR, MAT, MAT PVC, BA, MIRROR FINISH |
Form | Sheet , Plate , Coils, Farma & Different Shape as per drawing |
TEST CERTIFICATES | MTC, IBR & Third Party Inspection. |
---|
Stainless Steel 347/347H Sheets, Plate, Coils Mechanical Properties
Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
8.0 g/cm3 | 1454 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Chemical Composition of Stainless Steel 347/347H Sheets and Plates, Coils
Grade | C | Mn | Si | P | S | Cr | Cb | Ni | Fe |
SS 347 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 – 20.00 | 10xC – 1.10 | 9.00 – 13.00 | 62.74 min |
SS 347H | 0.04 – 0.10 | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 – 19.00 | 8xC – 1.10 | 9.0 -13.0 | 63.72 min |
Equivalent Grades of Stainless Steel 347/347H Sheets, Plates and Coils
STANDARD | WERKSTOFF NR. | UNS | GOST | EN | JIS |
SS 347 | 1.4550 | S347/347H00 | 08Ch18N12B | X6CrNiNb18-10 | SUS 347/347H |
SS 347H | 1.4961 | S34709 | – | X6CrNiNb18-12 | SUS 347H |
