Duplex Steel 2205 Fasteners
Duplex Steel UNS S31803 Fasteners, ASTM A182 Duplex Steel S32205 Fasteners, UNS S31803 Nuts, ASME SA182 Duplex Steel 2205 Bolts Exporter, DIN 1.4462 Screws, UNS S32205 Stud Bolt, Duplex Steel Washers, 2205 Duplex Steel Anchor Bolts, UNS S32205 Spring Washers, Duplex Steel Fasteners Manufacturer in India.
Rythme Alloys is a worldwide manufacturer of a wide range of Duplex Steel 2205 Fasteners. We are supplying and exporting superior quality fasteners to clients available around the globe. The fasteners are provided to the clients in different specifications such as surface finish, end finish, dimensions, shapes, sizes, length, and toughness. The fasteners are also available in the cut made specifications of the clients.
Duplex 2205 Fasteners is austenitic-ferritic steel, also known as the most demanding grade with a comprehensive range of properties. Duplex 2205 has a high ferrous content of up to 64 percent, a high nickel content of up to 7%, a high molybdenum content of up to 4%, and a low rest of element content of less than 2%. Duplex 2205 is developed and designed following national and international quality standards at our infrastructure facility to attain the highest quality grade. Duplex 2205 Fasteners has a working temperature of up to 300 degrees Celsius. However, At the temperature of 150ºC, it has chloride stress corrosion cracking and hence mainly used in marine environments. Duplex 2205 cannot be welded without filler material, which might result in excess ferrite.
Duplex Steel S31803 Hex Nuts Stockist, Duplex Steel S32205 Hex Head Bolt, ASTM A182 Duplex Steel Flat Washer, DIN 1.4462 Socket Head Cap Screws Trader, 2205 Duplex Steel Threaded Stud Bolts Dealer, Duplex Steel 2205 Lock Washer, Duplex Steel Heavy Hex Nuts Supplier in India.
Specification of Duplex 2205 Fasteners
Specification | EN, DIN, JIS, ASTM, BS, ASME, AISI, IS |
Size Range | M5 to M 1000 as per the requirement |
Length | 3 mm to 200 mm as per the requirement |
Type | Bolts, Nuts, Screws, Studs, Screw, Hex Set Screw, Socket Screw, Sockets,Hexagon Nut as per the requirement |
TEST CERTIFICATES | MTC, IBR & Third Party Inspection. |
---|
Duplex 2205 Fasteners Mechanical Properties
Element | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
S31803 / S32205 | 7.805 | 0.285 | 1420 – 1465 | 2588 – 2669 |
Chemical Composition of Duplex 2205 Fasteners
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
Duplex S31803 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 22.0 – 23.0 | 3.0 – 3.5 | 4.50 – 6.50 | 0.14 – 0.20 | 63.72 min |
Duplex S32205 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 21.0 – 23.0 | 2.50 – 3.50 | 4.50 – 6.50 | 0.8 – 0.20 | 63.54 min |
Equivalent Grades of Duplex 2205 Fasteners
STANDARD | UNS | WNR. |
Duplex 2205 | S31803 / S32205 | 1.4462 |
Physical Properties of UNS S31803 & S32205 Duplex Stainless Steel Fasteners
Density lbm/in3 | Electrical Resistivity mW•in | Thermal Conductivity (BTU/hr•ft•°F) | Heat Capacity BTU/lbm•°F | Electrical Resistivity (in x 10-6) | |
---|---|---|---|---|---|
at 68°F | 0.278 | 27.6 | 8.7 | 0.112 | 33.5 |
at 212°F | 26.1 | 9.2 | 0.119 | 35.4 | |
at 392°F | 25.4 | 9.8 | 0.127 | 37.4 | |
at 572°F | 24.9 | 10.4 | 0.134 | 39.4 |
