Stainless Steel 347 Pipes And Tubes
Stainless Steel 347 Pipes And Tubes, Stainless Steel 347 Pipe, SS 347H Seamless Pipe, 347 Pipes and Tubes Manufacturer in India.
Rythme Alloys is a leading supplier and stockiest of the industrial steel and SS 347/347H Pipes & Tubes. Our all the products are made with the high quality of the raw material and international standards. We even supply the customized form of the Pipes & Tubes and entire industrial steels. Our Stainless Steel 347 Pipes And Tubes are well tested and examined before the delivery to the clients and vendors.
SS 347/347H Pipes & Tubes are made with the help of both physical and mechanical properties like elongation, density, modules of expansion, thermal conductivity, electrical resistivity, tensile strength, yield strength, ultimate tensile strength, electrical conductivity, and proof stress as well. These pipes are constructed with the various types of specifications like grade, dimensions, tolerance, applications, types, forms, shape, size, schedule, finish, surface, length, width, thickness, and end as well. These tubes are available in various types such as seamless, welded, round, square, rectangular, polished, decorative, thick wall tubes, and electro polished as well. These pipes are made with several chemical combinations such as carbon, manganese, silicon, phosphorus, sulfur, chromium, nitrogen, nickel, and titanium.
SS ASTM A312 TP347H Seamless Pipes, SS 347 Tubing , SS 347 Welded Tube, ASTM A358 Stainless Steel 347H EFW Pipe Supplier, ASTM A213 Stainless Steel 347 Tubes Exporter, Stainless Steel 347 Pipes Manufacturer in India.
Stainless Steel 347 Pipes And Tubes Specification
Specification | EN, DIN, JIS, ASTM, BS, ASME, AISI, IS |
Size Range | 15 NB up to 600 NB above as per the customer requirement. |
Schedule | SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules. |
Type | Seamless / ERW / Welded / Fabricated / LSAW Pipes as per the requirement. |
Form | Round Pipe & Tube, Square Pipe & Tube, Rectangular Pipe & Tube |
Length | 1 to 6 Meters, Custom Cut Lengths |
End | Plain End, Beveled End, Threaded |
TEST CERTIFICATES | MTC, IBR & Third Party Inspection. |
---|
Stainless Steel 347 Pipes And Tubes Mechanical Properties
Grade | Tensile Strength ksi (MPa) min | Yield Strength 0.2% ksi offset ksi (MPa) min | Elongation (% in 50mm) min | Hardness (Brinell) MAX | Hardness (Rockwell B) MAX |
---|---|---|---|---|---|
347/347H | 75 (515) | 30 (205) | 40 | 201 | 95 |
Stainless Steel 347 Pipes And Tubes Chemical Composition
Element | C | Cr | Mn | Ni | P | S | Si | Cb/Ta |
---|---|---|---|---|---|---|---|---|
347 | 0.08 max | min: 17.0 max: 20.0 | 2.0 max | min: 9.0 max: 13.0 | 0.04 max | 0.30 max | 0.75 max | min:10x C max: 1.0 |
347H | min: 0.04 max: 0.10 | min: 17.0 max: 20.0 | 2.0 max | min: 9.0 max: 13.0 | 0.03 max | 0.30 max | 0.75 max | min:10x C max: 1.0 |
Stainless Steel 347 Pipes And Tubes Equivalent Grades
STANDARD | UNS | WNR. | EN | JIS | GOST |
---|---|---|---|---|---|
SS 347 | S34700 | 1.4550 | X6CrNiNb18-10 | SUS 347 | 08Ch18N12B |
SS 347H | S34709 | 1.4961 | X6CrNiNb18-12 | SUS 347H | – |
Pipes & Tubes Price List
- Duplex Welded Tube: US $0.5-1000 / Piece (FOB Price).
- Super Duplex ERW Pipes: US $300-500 / Ton (FOB Price).
- S32760 ERW Pipes: US $1-900 / Piece (FOB Price).
- 1.4410 Super Duplex Steel Seamless Pipe: US $0.5-1000 / Piece (FOB Price).
- Duplex 2507 Seamless Tube: US $1-300 / Piece (FOB Price).
