Stainless Steel 304/304L/304H Forged Fittings
Stainless Steel 304 Forged Fittings, SS ASTM A182 F304L Threaded Fittings, ASTM A182 Stainless Steel 304H Socket Weld Fittings Supplier, SS 304 Forged Threaded 90 deg Elbow, SS 304L Socket Weld Equal Tee, Stainless Steel 304H Forged Fittings, ASTM A182 Stainless Steel 304L Forged Tee Exporter, SS 304H Forged Fittings Manufacturer in India.
Rythme Alloys is among the leading producer, manufacturers, and suppliers, of Stainless Steel 304/304L/304H Forged Fittings. We provide you the best quality material of forged fittings. We provide the austenitic forged fittings of best quality stainless steel. We have an excellent team and professionals who will help you out in every step.
SS 304 forged threaded fittings are very less electrically conductive. It is also less thermal conductive as compared to other metals especially carbon steel. It is not magnetic. Stainless steel 304L forged threaded fittings have chromium, nickel, and carbon. SS 304/304L/304H forged fitting has to construct and welding properties. In addition to that, it has corrosion/oxidation resistance; it’s all due to the presence of chromium.
UNS S30400 Socket Weld 90 deg Elbow Trader, DIN 1.4301 Forged Pipe Fittings, Stainless Steel UNS S30403 / S30409 Hex Bushing, SS DIN 1.4307 Plug Dealer, ASTM A182 SS F304 High Pressure Forged Pipe Fittings, 304L Stainless Steel Socket Weld Union Stockists, ASME SA182 SS 304H Forged Fittings Supplier in India.
Specification of Stainless Steel 304/304L/304H Forged Fittings
| Stainless Steel Forged Fittings Specification | ASTM A182 / ASME SA182 |
|---|---|
| Dimension Standard | ASME B16.11, MSS-SP-79, MSS-SP-83, MSS-SP-95, MSS-SP-97, BS3799 |
| Size | 1/8″ NB to 4″ NB |
| Type | Socketweld Fittings, Screwed-Threaded Fittings (NPT or PT Type) |
| Rating Pressure | Threaded End – 2000 /3000/ 6000 LBS. Socket-weld End – 3000 / 6000/ 9000 LBS. |
Mechanical Properties Of Stainless Steel 304/304L/304H Forged Fittings
| Grade | Tensile Strength ksi (min) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Brinell) MAX | Hardness (Rockwell B) MAX |
|---|---|---|---|---|---|
| 304 | 75 | 30 | 40 | 201 | 92 |
| 304L | 70 | 25 | 40 | 201 | 92 |
| 304H | 75 | 30 | 40 | 201 | 92 |
Chemical Composition of Stainless Steel 304/304L/304H Forged Fittings
| C | Mn | Si | P | S | Cr | Ni | N | |
|---|---|---|---|---|---|---|---|---|
| 304 | 0.07max | 2.0max | 0.75max | 0.045max | 0.03max | min: 18.0 max: 20.0 | min: 8.0 max: 10.5 | — |
| 304L | 0.03max | 2.0max | 0.75max | 0.045max | 0.03max | min: 18.0 max: 20.0 | min: 8.0 max: 12.0 | 0.10 max |
| 304H | min: 18.0 max:20.0 | min: 8.0 max: 10.5 | min: 0.04 max:0.10 | 0.75 max | 2.0 max | 0.045 max | 0.03 max | 0.10 max |
304/304L/304H Stainless Steel Forged Fittings Equivalent Grades
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST |
|---|---|---|---|---|---|---|---|
| SS 304 | S30400 | 1.4301 | Z7CN18‐09 | X5CrNi18-10 | SUS 304 | 304S31 | 08Х18Н10 |
| SS 304L | S30403 | 1.4306/1.4307 | Z3CN18‐10 | X2CrNi18-9 / X2CrNi19-11 | SUS 304L | 304S11 | 03Х18Н11 |
| SS 304H | S30409 | 1.4301 | – | – | – | – | – |
