Monel K500 Pipes
Monel K500 Pipes, Monel K500 Tubes, Monel K500 Pipes and Tubes Manufacturer In India
Rythme Alloys takes pride in being one of the leading suppliers and manufacturers of Monel 400 Pipes. We have been serving a diverse group of clients with our quality products. We have been a part of this industry for years. We offer these pipes in various thickness measurements.
Monel 400 Tubes are made from nickel-copper alloy. It contains Nickel in high proportion and it contains a high percentage of copper as well. The combination of potent mechanical properties and chemical balance makes it resistant to seawater and steam at high temperatures. This is why industrial applications where high temperatures and voltage are a part of the process use these pipes. And similar properties prevail in salt and caustic solutions as well. The presence of nickel in Monel 400 Pipes determines many physical characteristics. Some of the most prominent are excellent corrosion resistance under the presence of all kinds of water and acids, good welding ability, and a high level of mechanical and tensile strength. This is suitable for all kinds of welding applications. But tungsten arc welding is most commonly used.
Monel K500 Tubes Exporter, ASTM B165 Monel Alloy K500 Seamless Pipes Manufacturer in India. Monel K500 Pipes, Monel UNS N05500 Pipes Dealer,ASME SB725 Monel K500 Welded Pipes, Monel K500 Seamless Pipe Trader
Monel K500 Pipes Specification
Specification | EN, DIN, JIS, ASTM, BS, ASME, AISI, IS |
Size Range | 15 NB up to 600 NB above as per the customer requirement. |
Schedule | SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules. |
Type | Seamless / ERW / Welded / Fabricated / LSAW Pipes as per the requirement. |
Form | Round Pipe & Tube, Square Pipe & Tube, Rectangular Pipe & Tube |
Length | 1 to 6 Meters, Custom Cut Lengths |
End | Plain End, Beveled End, Threaded |
TEST CERTIFICATES | MTC, IBR & Third Party Inspection. |
---|
Physical Properties of Monel K500 Pipes And Tubes
Density (Kg.m-1) | 84.3 |
---|---|
Magnetic Permeability (20°C) | <1.005 |
Curie Temperature (°C) | -90 |
Young’s Modulus (N/mm2) | 179 x 103 |
Specific Heat, 20°C (J.Kg-1.°K-1) | 418 |
Specific Electrical Resistance, 20°C (?O.m) | 0.62 |
Thermal conductivity,20°C (W.m-1.°K-1) | 17.5 |
Mean coefficient of thermal expansion, 20-100°C (°K-1) | 13.4 x 10-6 |
Monel K500 Pipes Mechanical Properties
Grade | Tensile (ksi) | .2% Yield (ksi) | Elongation % | Hardness (HRb) |
---|---|---|---|---|
K500 | Psi – 1,60,000 , MPa – 1100 | Psi – 1,15,000 , MPa – 790 | 20 % | – |
Monel K500 Pipes Chemical Composition
Grade | Ni | Fe | C | Mn | Si | Cu | Al | Ti | S |
---|---|---|---|---|---|---|---|---|---|
K500 | 63.0 min | 05 – 2 | 0.25 max | 1.5 max | 0.5 max | 27.0 – 33.0 | 2.3 – 3.15 | 0.35 – 0.85 | 0.010 max |
Monel K500 Tubes Equivalent Grades
STANDARD | UNS | WNR. | EN | JIS | GOST | AFNOR | BS |
---|---|---|---|---|---|---|---|
Monel K500 | N05500 | 2.4375 | – | – | – | – | – |
Pipes & Tubes Price List
- Duplex Welded Tube: US $0.5-1000 / Piece (FOB Price).
- Super Duplex ERW Pipes: US $300-500 / Ton (FOB Price).
- S32760 ERW Pipes: US $1-900 / Piece (FOB Price).
- 1.4410 Super Duplex Steel Seamless Pipe: US $0.5-1000 / Piece (FOB Price).
- Duplex 2507 Seamless Tube: US $1-300 / Piece (FOB Price).
